650nm 808nm 904nm Tri-Wavelength Superpulsed Laser Therapy System - Advanced Clinical Solution

COZING-T05-6

Technical Specifications

1. Triple-Wavelength Laser System

650nm Visible Red Laser (3 diodes @ 10mW each)
Penetration Depth: 0.5-2cm*
Primary Benefits: Anti-inflammatory effects, skin rejuvenation, superficial tissue repair

808nm Near-Infrared Laser (11 diodes @ 500mW each)
Total Output: 5.5W
Penetration Depth: 3-5cm*
Primary Benefits: Deep tissue healing, pain modulation

904nm Superpulsed Laser (11 diodes @ 25W peak power)

Average Power: 3.87mW
Penetration Depth: 5-10cm*
SP Technology: Nanosecond pulses for deep penetration without thermal damage

 2. Intelligent Control System

Power Adjustment: 10 precise levels (customizable energy output)

Frequency Modulation: 1-9999Hz programmable (continuous/pulse modes)

Treatment Timer: 1-99 minutes in seconds/minutes increments

Wavelength Selection: Flexible combination options

3. Advanced Probe Design

55mm Circular Treatment Head

23.76 cm² Irradiation Area

Optimized Beam Homogeneity

Scientific Photobiomodulation Mechanism

Therapeutic Effects by Wavelength

650nm Laser:

Stimulates mitochondrial activity → ↑ATP production

Enhances collagen synthesis (↑45% vs LED devices)

808nm Laser:

Modulates inflammatory cytokines (↓IL-6, ↑IL-10)

Improves microcirculation via vasodilation

904nm Superpulsed Laser:

Reaches deep neural tissues → pain signal inhibition

Activates stem cell proliferation

Synergistic Benefits

Comprehensive multi-layer tissue treatment

50% faster clinical results vs dual-wavelength systems

Customizable for various tissue depths and conditions

How Low-Level Laser Can Transform Your Health

Unlocking Healing power

For individuals recovering from breast cancer surgery, managing post-surgical scarring, or dealing with chronic conditions like lymphoedema and lipoedema, the journey to healing can be long and challenging. Fortunately, low-level laser therapy (LLLT) with the T05-6 device offers a non-invasive, highly effective option to accelerate recovery, reduce pain, and improve overall well-being.

The T05-6 Low-Level Laser is revolutionising the way we approach recovery after breast cancer surgery and managing conditions like lymphoedema and lipoedema, helping patients heal faster and more effectively.

T05-6 and Lymphoedema: A Targeted Approach

Lymphoedema, a condition commonly seen after surgery, is characterised by swelling, often in the arms or legs, due to a compromised lymphatic system. The T05-6 is particularly effective in managing this condition by stimulating lymphatic drainage and improving the circulation of lymph fluid.

What to Expect from T05-6 Treatment

Treatment with the T05-6 typically lasts between 5-15 minutes, and the device is applied directly to the area of concern. For those recovering from breast cancer surgery or managing lymphoedema, treatment can be done on the arms, chest, or other affected areas to reduce swelling, promote healing, and improve tissue function.

Empower Your Recovery with the T05-6

The T05-6 Low-Level Laser is an exciting tool in the management of breast cancer rehabilitation, lymphoedema, and lipoedema. By using the power of light to stimulate healing, reduce swelling, and improve tissue regeneration, this innovative therapy offers an effective, non-invasive solution for those seeking to regain their health and vitality.

Why Choose the T05-6 for These Conditions?

The T05-6 offers a non-invasive, pain-free, and safe treatment for recovery from breast cancer surgery, managing lymphoedema, or living with lipoedema. Its benefits are backed by science, with research showing that low-level laser therapy promotes tissue regeneration, reduces inflammation, and enhances lymphatic flow—all essential elements for improving the quality of life for individuals dealing with these conditions.

For those who have undergone breast cancer treatment, one often faces a variety of recovery challenges, including scarring, lymphoedema, and reduced mobility. The T05-6 offers an alternative to more invasive treatments, providing a safe and effective way to reduce pain, speed recovery, and improve overall well-being.

Low-Level Laser can provide significant relief for individuals with lipoedema in the following ways:

• Reduction in Swelling and Inflammation: Lipoedema often leads to swelling and a sensation of heaviness in the legs, arms, or other affected areas. The T05-6 helps to stimulate the lymphatic system, encouraging the reduction of excess fluid and inflammation, and providing relief from the heaviness and discomfort associated with lipoedema.

• Pain Management: The laser’s ability to increase circulation and promote tissue repair helps reduce the pain and tenderness that is commonly associated with lipoedema, particularly in the legs and thighs.

• Improved Skin Tone and Texture: Lipoedema often causes the skin to appear uneven or dimpled. The T05-6’s stimulation of collagen production can improve the elasticity and appearance of the skin, promoting a smoother texture over time. (N.B. There are key differences between the collagen found in lipoedema tissue and the collagen stimulated by LLLT)

Benefits of LLLT for Axillary Web Syndrome (Cording):

1. Reduces Pain and Inflammation: After breast cancer surgery, cording can develop due to lymphatic damage and scar tissue formation, causing tight, rope-like bands under the skin. This often leads to pain, particularly when stretching or lifting the arm. The T05-6 laser uses a specific wavelength (904nm) that penetrates deep into tissues, reducing inflammation and alleviating pain. By modulating pain pathways and inhibiting pain signals, the laser offers a safe, drug-free method of pain management.

2. Improves Range of Motion and Flexibility: Cording can significantly restrict arm movement, affecting daily activities and slowing down rehabilitation. The T05-6 laser enhances blood flow and lymphatic circulation, helping to soften the cords and reduce tissue tightness. This improved flexibility allows patients to perform stretching exercises with less discomfort, facilitating a quicker return to normal arm function.

3. Accelerates Tissue Healing: Surgical trauma can lead to scar tissue development, contributing to cording and muscle stiffness. By promoting cellular regeneration, LLLT helps break down scar tissue, reduces fibrosis, and supports tissue repair, thus accelerating recovery. This is particularly beneficial in the early stages post-surgery, preventing cording from becoming a long-term issue.

The laser therapy works at the cellular level to stimulate the mitochondria in the cells, increasing energy production (ATP) and encouraging faster tissue repair. This results in:

• Improved lymphatic flow, helping to reduce swelling in affected limbs.

• Enhanced detoxification, as the laser helps the body flush out waste products and excess fluid.

• Reduced inflammation, which is often a key factor in the pain and discomfort associated with lymphoedema.

For those with breast cancer-related lymphoedema, the T05-6 can significantly improve limb mobility, reduce swelling, and enhance overall comfort, which can make everyday activities more manageable.

Competitive Advantages vs Western Laser Systems

Evidence-Based Treatment Protocols

Protocol 1: Severe Osteoarthritis

Wavelengths: 808nm (60%) + 904nm (40%)

Power: Level 8

Mode: Pulsed @ 250Hz

Duration: 12 minutes

Frequency: 3x/week

 Protocol 2: Acute Sports Injury

Wavelengths: 904nm superpulse only

Power: Level 9

Mode: 1000Hz burst pulses

Duration: 8 minutes

Frequency: Daily for first 3 days

 Protocol 3: Diabetic Foot Ulcer

Wavelengths: 650nm + 808nm combo

Power: Level 5

Mode: Continuous

Duration: 10 minutes

Frequency: Daily until healed

Clinical Applications & Therapeutic Indications

• Chronic Pain Management: Osteoarthritis, rheumatoid arthritis, fibromyalgia
• Sports Medicine: Muscle tears, ligament injuries, post-surgical recovery
• Neurological Disorders: Peripheral neuropathy, sciatica, post-stroke rehabilitation
• Wound Care: Diabetic ulcers, pressure sores, burn healing
• Inflammatory Conditions: Tendinitis, bursitis, carpal tunnel syndrome
